RIVER ilm Passive speaker simulation DI box

Item No.: PILM
Series: River
Analog Speaker simulation for authentic guitar sound without mic
Three sound settings: normal, mellow, bright
Can be used as DI box with speaker simulation bypassed
Balanced XLR output
Operation either between amplifier output and speaker or on the line output
Switchable pre-attenuation for adjustment to amp levels
No humming: galvanic transformer isolation
Ground lift switch
Simple and fail-safe, no power supply required
Solid casing made of aluminium and steel
Incl. rewritable tour label for attachment onto the back of the ilm
Engineered in Germany


Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results
Analog Speaker simulation for authentic guitar sound without mic
Three sound settings: normal, mellow, bright
Can be used as DI box with speaker simulation bypassed
Balanced XLR output
Operation either between amplifier output and speaker or on the line output
Switchable pre-attenuation for adjustment to amp levels
No humming: galvanic transformer isolation
Ground lift switch
Simple and fail-safe, no power supply required
Solid casing made of aluminium and steel
Incl. rewritable tour label for attachment onto the back of the ilm
Engineered in Germany
Description

You've found your perfect amp sound, but somehow it sounds different on every stage?

The Palmer ilm speaker simulation DI box removes all the uncertainties of amp micing such as microphone choice, acoustic environment and positioning. With a sophisticated filter switch simulating the sound behaviour of a real guitar speaker, it captures your authentic sound, even without a microphone. Its direct signal always sounds the same, whether at home, in the (home) studio, during rehearsals, or on stage, whatever the room size.

The Palmer ilm offers three analog guitar speaker simulation settings, which represent typical guitar speaker models. We'll leave the flowery names to the others; on the Palmer ilm , they are called "normal", "mellow" and "bright".

Generally, the Palmer ilm is looped in between the guitar amp output and guitar speaker; but it can also be operated on the amplifier's line out. For input-level adjustment, the ilm has a pad switch with three settings: 0, -15 and -30 dB.

The output of the Palmer ilm is balanced and transformer isolated which means there is no interference or ground loop hum when connecting it to a mixing console or audio interface. With the Palmer ilm, you can always rely on what really matters: Your music, your instrument and your sound.

Ilm - River Series
Ilm - River Series
Ilm - River Series
Ilm - River Series
Specifications
General
Product type
Speaker Simulation DI-Box
Type
passive
Channels
1
Transformer isolated
Yes
Number of inputs
1
Input type
unbalanced
Input connectors
6.3 mm jack
Outputs
1
Output type
balanced
Output connectors
XLR
THRU outputs per channel
1
Ground lift switch
Yes
More features
Tone: Bypass, Normal, Bright, Mellow
Housing material
Aluminium continuous casting
Height
140 mm
Width
50 mm
Depth
68 mm
Ambient temperature (in operation)
- 20 - 70 °C
Relative Humidity
< 80 %, not condensing
Accessories (included)
Inscription label (tour label), rubber feet
Weight
0,445 kg
Audio
Max. input level (< 1% THD, 20 Hz)
+12 dBu
Max. input level (< 1% THD, 1 kHz)
+32 dBu
Frequency response (±1 dB, relative 1 kHz)
10 Hz - 60 kHz
Input impedance (1 kHz, max. Level, -10dBV)
8,8 kOhm
Output impedance (1 kHz, max. Level, -10dBV)
125 Ohm
THD (30 Hz, +4 dBu, unity, unweighted)
< 0,25 %
THD (1 kHz, +4 dBu, unity, unweighted)
< 0,009 %
IMD (SMPTE) (60 Hz / 7 kHz, 4:1, +4 dBu)
< 0.005 %
Transformer ratio
1:5

RIVER SERIES

The River Series represents the pinnacle of Palmer's commitment to delivering exceptional audio tools. It is a harmonious blend of pure, high-quality sound, rugged and reliable design, and thoughtful, user-friendly features. Let the River Series carry your sound naturally and powerfully into the hearts of your listeners. Experience the River Series - where your sound flows.

We know that the demands of stage and studio require equipment that is not only high performing, but also rugged and durable. The River Series represents a new design philosophy that combines form and function to create audio tools that are as rugged as they are stunning. These units are built to last, with rugged metal chassis and reinforced connectors. We've tested them in the harshest conditions, so you can count on the River Series to deliver, gig after gig, session after session, year after year.

Tough and durable new design

We know that the demands of stage and studio require equipment that is not only high performing, but also rugged and durable. The River Series represents a new design philosophy that combines form and function to create audio tools that are as rugged as they are stunning. These units are built to last, with rugged metal chassis and reinforced connectors. We've tested them in the harshest conditions, so you can count on the River Series to deliver, gig after gig, session after session, year after year.

Rewritable Tour Labels

In the world of professional audio, organisation is king. Misplaced or incorrectly connected equipment can turn a flawless performance into an unforgettable disaster. That's why the River Series introduces an innovative feature: rewritable tour labels. These color coded handy labels let you customize your di-boxes, line isolators splitters & mergers, ensuring each piece is in the right place, every time whether in the busy backstage area of a rock concert or the tangled web of cables in a recording studio.

Rewritable Tour Labels

In the world of professional audio, organisation is king. Misplaced or incorrectly connected equipment can turn a flawless performance into an unforgettable disaster. That's why the River Series introduces an innovative feature: rewritable tour labels. These color coded handy labels let you customize your di-boxes, line isolators splitters & mergers, ensuring each piece is in the right place, every time whether in the busy backstage area of a rock concert or the tangled web of cables in a recording studio.

Tough and durable new design

We know that the demands of stage and studio require equipment that is not only high performing, but also rugged and durable. The River Series represents a new design philosophy that combines form and function to create audio tools that are as rugged as they are stunning. These units are built to last, with rugged metal chassis and reinforced connectors. We've tested them in the harshest conditions, so you can count on the River Series to deliver, gig after gig, session after session, year after year.

Tough and durable new design

We know that the demands of stage and studio require equipment that is not only high performing, but also rugged and durable. The River Series represents a new design philosophy that combines form and function to create audio tools that are as rugged as they are stunning. These units are built to last, with rugged metal chassis and reinforced connectors. We've tested them in the harshest conditions, so you can count on the River Series to deliver, gig after gig, session after session, year after year.

Rewritable Tour Labels

In the world of professional audio, organisation is king. Misplaced or incorrectly connected equipment can turn a flawless performance into an unforgettable disaster. That's why the River Series introduces an innovative feature: rewritable tour labels. These color coded handy labels let you customize your di-boxes, line isolators splitters & mergers, ensuring each piece is in the right place, every time whether in the busy backstage area of a rock concert or the tangled web of cables in a recording studio.

Let your signals flow, naturally and powerfully like a river!

Let your signals flow, as naturally and powerfully as a river! The River Series embodies this claim down to the last detail: with high-precision circuitry designed by our award-winning engineers so your sound remains uncoloured until it reaches its destination: the heart of your listeners. That’s exactly what Palmer® stands for. Since 1980, we've been manufacturing audio tools for professional use on stage, in broadcast, and in the studio. Musicians and sound engineers all over the world value our solutions, developed in Germany, for their unobstructed signal flow and pure sound – crystal clear and as alive as water! So what could be more fitting than to name the River Series models after German rivers?

Lass deine Signale fließen, natürlich und kraftvoll wie ein Fluss! Die River Series verkörpert diesen Anspruch bis ins Detail: Mit hochpräzisen Schaltungen, designt von unseren preisgekrönten Ingenieuren, damit dein Sound unverfälscht sein Ziel erreicht: das Herz deiner Zuhörer. Denn genau dafür steht Palmer®. Schon seit 1980 fertigen wir Audio-Tools für den professionellen Einsatz auf der Bühne, beim Rundfunk und im Studio. Musiker und Toningenieure weltweit schätzen unsere in Deutschland entwickelten Lösungen für ihren ungehinderten Signalfluss und reinen Klang – kristallklar und lebendig wie Wasser! Was lag also näher als die Modelle der River Series nach deutschen Flüssen zu benennen? Entdecke unsere zuverlässigen und bewährten DI-Boxen, Re-Amp Boxen, Line-Isolatoren, Splitter und Summierer.

WE ASSEMBLE ALL BOXES HERE IN EUROPE BY HAND!

What is a DI-Box?

DI-Boxes convert unbalanced or high-impedance instrument signals into a signal for direct connection to the microphone input of a mixing console.

Learn more

Do I Need A DI Box For My Guitar?

Learn how a DI box prevents muffled and quiet sounds by optimising guitar and bass signals for mixers and audio interfaces.

Learn more
